Dimension
12.4" x 9.1" x 1.8" (315 x 230 x 45 mm)
Capacity
Up to 6TB for Each Disk
Power Consumption
≤ 10 watts (without hard disk)
Operating Temperature
+14 ~ +131°F (‑10 ~ +55°C)
Operating Humidity
10 ~ 90% RH, noncondensing
Audio Output
1‑CH, RCA (Linear, 1kΩ)
Network Interface
1 RJ45 10/100/1000 Mbps self‑adaptive Ethernet interface
Weight
≤ 4.4 lbs. (2.0 kg) (without hard disk)
Recording Resolution
6MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Frame rate
Main stream: 50 fps (P) / 60 fps (N)Substream: 50 fps (P) / 60 fps (N)
Recorder series
Platinum Series
Recorder channels
4‑Channel
Recorder case
Compact Case
Recorder technology
IP / NVR
Incoming bandwidth
40Mbps
Outgoing bandwidth
80Mbps
Sata
1 SATA interface for 1 HDD
Two‑way audio input
1‑ch, RCA (2.0 Vp‑p, 1kΩ)
Hdmi®/vga output
1‑ch, resolution:1920 x 1080P/60Hz, 1600 x 1200/60Hz,1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz
Live view playback resolution
6MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Usb interfa e
1x USB 2.0 and 1x USB 3.0
Poe interface
4 independent 100 Mbps PoE
