Paneltronics Digital Dc Ammeter - 0-100Dca 12/24 Volts System

SKU: CWR-70352
Out of stock
Out of stock
Unit Price
Quantity
US$ 165.13
Out of stock
Options
Brand
Barcode
602290303023
Description

Digital DC Ammeter - 0-100DCA 12/24 Volts System

Specifications:

  • Monitor marine/land based power distribution & generating systems (ABYC E-11.9.3.2.)
  • AC voltmeter and AC ammeter are true RMS (ABYC E-11.9.3.2.)
  • Surface mount with only two 5/32" diameter holes
  • Window mount in standard 2.5" analog meter cutout (2.90" W X 1.28" H)
  • Three digit LED display (Frequency meters are two digits)
  • Reversed Polarity Protected
  • Splashproof front
  • Includes pigtails, mounting hardware, & instructions
  • Display Character Size: 9/16"
  • Input Voltage: 8-32VDC
  • Power Consumption: 1Watt 12/24VDC
  • Accuracy: +/- 1 Count
  • Operating Temperature Range: 32-122 deg. F
  • Dimensions: 3.08"W, 2.38"H, 1.0"D
  • Shipping specs
    Weight
    0.45 lbs
    Dimensions
    5" x 4" x 4"
    Shipping weight
    0.45 lbs
    Shipping dimensions
    4" x 4" x 5"
    Shipping from
    This product is shipped from our supplier's warehouse in , NJ, United States
    Our guarantee
    This product is brand new and includes the manufacturer's warranty, so you can buy with confidence.
    A 25% handling charge is levied against all authorized returns except those due to our error. Unauthorized returns are subject to a 40% handling charge. Damages & defects must be reported to us within 14 days.
