Paneltronics Breaker 5 Amps A-Frame Magnetic Waterproof

SKU: CWR-29828
Unit Price
Quantity
Subtotal
US$ 34.29
US$ 34.95
US$ 34.29
US$ 34.95
US$ 34.081%
2
US$ 33.961%
3
Congratulations! You got a great price!
Add to cart Added
Checkout
Options
Brand
Paneltronics
Color
Stainless
Throw/Pole
SPST
Barcode
602290201404
Description
  • Branch AC or DC circuit breaker for Paneltronics electrical distribution panels
  • Meets all American Boat and Yacht Council (ABYC) Standards for non-ignition protected circuit breakers
  • UL Recognized (UL 1077) for use in th USA, and CSA Certified for use in Canada
  • Trip free (ABYC E-11.10.1.5.4 and E-11.10.2.1.1)
  • Manual reset (ABYC E-11.10.1.5.6 and E-11.10.2.1.1)
  • Handle Color - Metal with silicon rubber seal
  • Maximum Aperage - 50 Amps
  • Maximum Voltage/AIC - 32 VDC/2,500 amps with no back-up fuse (ABYC E-11.10.1.5.5)
  • Rated Switch Cycles - 10,000 actuations at rated current and voltage
  • Electrical Hardware - Hex nut 1/2-32 (supplied with circuit breaker); Lockwasher 1/2" internal tooth (supplied with circuit breaker)
  • Optional Boot - Black silicone rubber (P/N 048-015)
    • Shipping specs
    Weight
    0.2 lbs
    Dimensions
    2" x 2" x 2"
    Shipping weight
    0.2 lbs
    Shipping dimensions
    2" x 2" x 2"
    Shipping from
    This product is shipped from our supplier's warehouse in NJ, United States
    Our guarantee
    This product is brand new and includes the manufacturer's warranty, so you can buy with confidence.
